39EmCORE-i612VLS/C400 User's Manual
Setup The system will boot, but access to Setup will be denied if the
correct password is not entered at the prompt.
Note To disable security, select PASSWORD SETTING at Main Menu and
then you will be asked to enter password. Do not type anything and
just press <Enter>, it will disable security. Once the security is
disabled, the system will boot and you can enter Setup freely.
APIC Mode
Select
OS Select For DRAM > 64MB
Select the operating system that is running with greater than 64MB of RAM on
the system.The choice: Non-OS2, OS2.
Console Redirection
Console Redirection capability allows a system with no keyboard and no
video hardware to transmit video and keyboard data to a host system via the
serial port.
Video BIOS Shadow
Enabled this copies the video BIOS from ROM to RAM. effectively enhancing
performance, and reducing the amount of upper memory available by 32KB
(the C0000~C7FFF area of memory between 640 KB and 1 MB is used).
C8000-CBFFF Shadow
Enabling any of the C8000~CBFFF segments allows components to move their
firmware into these upper memory segments. However your computer can
lock-up doing so, because some devices don't like being shadowed at those
particular 16 KB segments of upper memory.
Small Logo(EPA) Show
[Enabled]: If you want to show your logo, please enable it.
[Disabled]: When this item disabled, logo(EPA) will not show on screen.
EEPROM Write Protect
All the configuration data is stored in a type of nonvolatile memor chip called
an EEPROM. When it's enabled, it disables all writes to the configuration
EEPROM. This locks your current configuration against accidenatal or unautho-
rized changes.
Note - In Windows 95, double click 'Computer' within Device Manager and
select 'Memory'. This will tell you what segments (if any) are being shadowed
For DOS you can use MSD.EXE to see what segments are claimed.
CC000-CFFFF - D0000-D3FFF - D4000-D7FFF - D8000-DBFFF and
DC000-DFFFF - Same as above.
