42 EmCORE-i612VLS/C400 User's Manual
On-Chip Video Window Size
Select the on-chip video window size for VGA drives use.
Onboard Display Cache Setting
Setting the onboard display cache timing
CAS#Latency
Select the local memory clock periods
Paging Mode Control
Select the paging mode control
RAS-to-CAS Override
Select the display cache clock periods control
RAS# Timing
This item controls RAS# active to Protegra, and refresh to RAS# active delay
( in local memory clocks).
RAS# Precharge Timing
This item controls RAS# precharge ( in local memory clocks).
