Contex SD One+ - Belt Tension (Motor)

Service Guide SD One+ 12
Belt tension (Motor)
Tools:
T15 Torx Screwdriver.
Prerequisites:
Switch power off.
Raise CIS Bridge Unit as shown on page 11.
Remove RHS cover, see page 20.
1. Loosen the Locking screw.
2. Rotate the drive shaft without touching the belt.
3. Tighten the locking screw.
4. Remount the Cover
