Contex SD One+ - WIDEsystem Service Procedures

Service Guide SD One+ 40
Appendix A
WIDEsystem Service, walk though
 Since this chapter is not scanner specific, some of the illustrations may not apply completely to the scanner you are working on, like
number of Cameras and transition areas.
 Widesystem / Service consists of 17 different tests designed to help you service the scanner. These test are divided on 5 different tabs
according to what you are doing on the scanner.
Paper Path/Handling
Image Quality
Electrical
Utilities
Post Replacement
Some of the tests may appear on one or more tab’s. Each test is also associated with a number for easy reference.
No.
Name.
Tab.
1
Set Serial no.
(Post Replacement)
6
Motor Test
(Electrical, Post Replacement)
9
Oscilloscope View Cameras
(Image Quality, Post Replacement)
11
Manual Camera (alignment & Stitching)
(Image Quality)
12
Manual Scaling
(Image Quality, Post Replacement)
20
Streak / Noise Test
(Image Quality)
42
Backup Calibration and Statistics
(Utilities)
43
Restore Calibration and Statistics
(Utilities, Post Replacement)
46
Paper Sensor Test
(Paper Path/Handling, Post Replacement)
