Service Guide SD One+ 19
Fig
Part no.
SD One+ 24”
SD One+ 36”
Description
Service parts
3-03
2853D101
X
SULO Controller Board (SD One+ 24)
3-03
2853D102
X
SULO Controller Board (SD One+ 36)
3-02
0075A160R01
X
X
Paper/Lid Sensor (1 pcs.)
1-04
2853D105
X
X
CIS Element (1 pcs) (LSH1208)
3-01
2853D107
X
Cable Set for CIS Elements (3 pcs)(24’’)
3-01
2853D106
X
Cable Set for CIS Elements (5 pcs)(36’’)
2-01 & 2-02
2853D108
X
Power Inlet Assy, SD One+ 24
2-01 & 2-02
2853D109
X
Power Inlet Assy, SD One+ 36
2-03
0090B087R01
X
X
USB2.0 Cable, Panel Mount
2-04
2853D104
X
X
Stepper Motor, STA-42D2014
2-05
2853D110
X
X
Damper Assy. for CIS Bridge, SD One+
1-02
2853D111
X
X
LHS Cover, SD One+
1-01
2853D112
X
X
RHS Cover, SD One+
-
2853D127
X
Top Lid Cover incl. Control Panel (SD One+ 24)
-
2853D128
X
Top Lid Cover incl. Control Panel (SD One+ 36)
Consumable’s & Customer replaceable parts
1-05
5229D014R01
X
Glass Plate, 24”
1-05
5398A008
X
Glass Plate, 36”
1-03
2853D115
X
Pressure Rollers (SD One)(3 pcs)
1-03
2853D116
X
Pressure Rollers (SD One)(5 pcs)
N/A
2853D113
X
Calibration Sheet, SD One+ 24
2853D114
X
Calibration Sheet, SD One+ 36
5398A009
X
X
USB2.0 Cable with Ferrite, A/B, 3m
2853D103
X
X
DC Adapter, SD One+
