Service Guide SD One+ 22
5. Release the locking bar to allow the Ribbon cable
to be removed.
6. Remove screws (2 x T10).
7. Lift out the board from under the retaining clips.
8. Replace the Scanner Controller board and the reverse the steps.
Post actions
Since the scanner has a new Controller board it will boot up as “Not Activated”. See Appendix E for further instructions on how to
reactivate the scanner.
Since it’s a new board it does not hold any calibration data and will therefore need to be calibrated.
Calibration is done though WIDEsystem.
