Problems Related to the Scanning Results
Problem Possible Causes and Remedies
Entire image is not scanned
1. Check in your scanning application that your size settings are either for Auto detection or correspond to the size of the whole
original.
2. Check in your scanning application that you are loading the original correctly. Be sure to align the center of the original with
the scanner’s center arrow marking.
Stitching problems – Image sections
misaligned (at points between the sensors
-overlapping pixels)
1. Remove the original from the scanner and calibrate the scanner with the Scanner Maintenance program. Calibration includes
correction of stitching errors.
2. If the problem persists after calibration – Your sensors may need readjusting. Summon your technical service provider.
One or more thin vertical lines (in the
direction of paper feeding) show up in the
scanned image, but not in the original
drawing.
This is often caused by an unclean glass plate. Even a single spec of dirt in the wrong spot on the glass plate can apply a streak
along your entire scan. To remedy:
1. Clean your glass plate and rollers as described in this users’ guide.
2. Most dirt on the glass plate is introduced by the documents that are passed against it. Wipe clean the document with a dry
lint-free cloth before feeding the document into the scanner.
3. If the problem persists after cleaning, calibrate the scanner with the scanner maintenance program. The scanner may have
memorized dirt specs and you need to recalibrate after dirt-removal.
4. If the problem persists after cleaning and calibration –Check the glass plate for scratches. A damaged glass plate should be
replaced. Obtain a new glass plate from your service provider. Follow the steps in the user’s guide to replace the glass plate
with a new one.
