Page 31
Terminal Strip Connections
Enclosed Model
Standard Start / Stop & Speed Potentiometer Connections
Drive will not start
without this. This is
intended for system
interlock- see
Application Safety
The Start/Stop Switch
And the Speed
Potentiometer are
supplied as shown on
the drive cove
r
1
2
6
3
4
5A
5
7
8
Stop Start
Speed
Potentiometer
TB2
