Control Techniques Unidrive 1401 User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Menu 0
Running
the motor
Optimisation Macros
Advanced
Parameters
Technical
Data
Diagnostics
UL Listing
Information
Unidrive User Guide 9
Issue Number: 9 www.controltechniques.com
2.3 Nameplate description - drive
identification
The drive label is found on the top surface of the control pod (right
angles to the display) on Unidrive sizes 1 to 3 and size 5 control module,
and on the side of the Unidrive size 4 and size 5 power module.
Figure 2-1 Typical drive rating labels
2.4 Model variants
2.4.1 Unidrive standard industrial (STD)
...for constant torque loads (All frame sizes)
Operating modes:
Open Loop
Closed Loop vector
Servo
Regen
Overload:
Open loop 150% for 60s
Closed loop vector 175% for 60s (sizes 1 to 4), 150%* for 60s (size
5)
Servo 175% for 4s (sizes 1 to 4), 150%* for 4s (size 5)
Regen 150% for 60s
* Multiples of 300A output current with 120% overload or multiples of
240A with 150% overload
Figure 2-2 Constant torque load
Model
D
r
i
ve type
(STD,LV,
VTC, LFT)
Power rating
Customer and
date code
Approval
s
Drive
ratings
UNI3401 VTC 15kW
STDJ41
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.
VOLTAGE 50/60 Hz 3Ph
INPUT OUTPUT
380/480V 380/480V
CURRENT (A)
27A 34.0A
OVERLOAD: 40.8A FOR 60 SECS
SOFTWARE VERSION: 03.02.11
R
IND.
CONT..
EQ.
MADE IN THE U.K.
UNIDRIVE SIZE 5
CONTROL MODULE HW2
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.

R
IND.
CONT..
EQ.
MADE IN THE U.K.
TO BE USED IN CONJUNCTION
WITH UNIDRIVE SIZE 5 HW2
POWER MODULES (S)
SOFTWARE VERSION: 03.02.11
3000005001
STDL01
Approvals
Customer and
date code
M
o
d
e
l
Hardware
revision
CE approval Europe
C Tick approval Australia
UL / cUL approval
USA &
Canada
R
UNI5401 POWER MODULE HW2 110V FAN FITTED STDL01
IT IS ESSENTIAL TO READ
THE MANUAL BEFORE
CONNECTING THE DRIVE.

VOLTAGE 50/60 Hz 3Ph
INPUT OUTPUT
380/480V 380/480V
CURRENT (A)
220.0A 240.0A OVERLOAD: 150 FOR 60 SECS
OVERLOAD: 120 FOR 60 SECS
280.0A 300.0A
R
IND.
CONT..
EQ.
HEATSINK FAN
110V/120V 50/60HZ
MADE IN
THE U.K.
Approvals
Customer and
date code
M
o
d
e
l
Drive
ratings
Dual current
ratin
g
Heatsink fan
ratings
Unidrive size 1 to 4 rating label
Unidrive size 5 control module rating label
Unidrive size 5 power module rating label
Key to Approvals
100
80
60
40
20
0
50 10
0
Percent kW
and torque
Percent s
p
eed
Torque
kW
