17
Cassette
Installation
Bracket
Bracket
Cassette Side Prole
Bracket
Snap into place
Cassette
Side Prole
•
Center the Brackets over your three bracket marks, ensuring the
spring-loaded Release Tabs are pointed down for easy removal and
mark the screw holes (g. C).
WARNING: Must be mounted into wood/metal studs or concrete
anchors. Mounting with drywall anchors is NOT recommended.
•
Drill pilot holes using a ⁄" drill bit.
•
Level the mounting surface and shim the brackets if necessary, then
attach brackets using screws provided (g. C).
STEP 2: Install the Shade
Click the shade onto the Cassette Brackets, placing the top of the channel onto the bracket. Push down on the
full Cassette and push in the Release Tabs until they snap into place (g. D).
INSTALLATION: CASSETTE Shade — WALL Mount
Release Tab
Pointed Down
C
D
Release Tab Release Tab
To Next Page
