Coolaroo Custom - Cassette Shade - Wall Mount

16
Opening
Bracket
Mark
3″ 3″
Bracket
Mark
Center Bracket Mark
STEP 1: Mount the Brackets
•
Three installation brackets are required.
IMPORTANT: The front edges of the installation Cassette Brackets must be level and aligned with each
other. A minimum of 4″ at, vertical surface is required to mount brackets. The top of the installation
Cassette Brackets should be installed 1 ⁄" below the ordered height (g. B).
•
To nd the bracket locations measure and mark the center of the opening where you want to mount the
shade. That will be the Center Bracket Mark (g. A1).
•
Find the Marking Distance by measuring the width of the entire Cassette and dividing by 2 (g. A2).
•
Mark the Cassette Edges by measuring the Marking Distance from the center point outward on each side
(g. A3).
•
Mark 3″ in from each Cassette Edge for the other two bracket locations (g. A4).
INSTALLATION: CASSETTE Shade — WALL Mount
4 ¹⁄″
3 ³⁄″
1 ⁄″
3 ¹¹⁄″
Cassette Side Prole
Bracket
B
A1
Cassette
Edge
Cassette
Edge
Marking DistanceMarking Distance
A3
A4 A4
A3
A2A2
