STEP 1: Mount the Brackets
•
Three installation brackets are required.
•
To nd the bracket locations mark 3″ in from each side for two of the bracket locations and mark the center
between the two end brackets for the third (g. A).
IMPORTANT: The front edges of the installation Cassette Brackets must be level and aligned with each
other. The minimum depth required for mounting is 3″. Fully recessed mounting requires at least 4″ depth for
Cassette to be ush with opening (g. B).
Opening
Cassette Side Prole
Bracket
INSTALLATION: CASSETTE Shade — TOP Mount
