Coolerado Installation
Page 35 of 63
Level 1
Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
Equipment
Setup (Cont.)
Reheat Min Damper Position*
20%
0 to 100%
*VAV units with reheat installed
Reheat Fan Required*
No
Yes or No
*Fan coil units with reheat installed
Reheat Min On Time*
180 seconds
0 to 360 second
* Reheat installed
Reheat/ Min Off Time*
180 seconds
0 to 360 seconds
* Reheat installed
Changeover
Changeover Mode
Cooling
Auto, Cooling, or Heating
* Non 4-Pipe units
Supply Temp Type
Analog Sensor
Analog Sensor, Heating NC, Cooling NC
* Changeover Mode = Auto
Changeover Setpoint
55°F
40 to 200°F (4 to 93°C)
* Supply temp type = analog sensor
Supply Temp Sensor
Nickel
Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
* Supply temp type = analog sensor
Supply Temp Offset
0°F
-5 to 5°F (-3 to 3°C)
* Supply temp type = analog sensor
Level 1
Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
System Status
Occupancy Source
Local Schedule
Occupancy BI
Temp Occ BI
Temp Occ
Occ Override
Local Schedule
BAS Schedule
Occupancy Sensor
Unit Status
Cooling
System Fault
Airflow Fault
Open Window
Control Off
Unreliable Temperature
Dehumidification
Idle
Cooling
Heating
Cooling Unavailable
Heating Unavailable
Cooling Unavailable due to Changeover
Cooling Unavailable due to OA Temp
Cooling Unavailable due to Control Mode
Heating Unavailable due to Changeover
Heating Unavailable due to OA Temp
Heating Unavailable due to Control Mode
Supply Air Temperature
75°F
-50 to 250°F (-45 to 121°C)
