Supply Temp Sensor*
Nickel
Nickel, Platinum, A99B, 2.25k ohm
negative temperature coefficient (NTC),
10k ohm NTC, 10k ohm NTC Type 3
* Analog and non-four pipe units
Supply Temp Offset*
0 degrees
-5 to 5 degrees (F or C based on Units
setting under Display Settings menu
* Analog Sensor
Zone Temp Sensor
Nickel
Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
* Analog Sensor
Zone Temp Sensor Offset
0 degrees
-5 to 5 degrees (F or C based on Units
setting under Display Settings menu
Humidity Offset
0% RH
-15% to 15% RH
Reset Sensors
False
True or False
Level 1
Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
Network Setup
FC Comm Mode
BACnet/MSTP
BACnet/MSTP, N2
BACnet Instance ID*
4
0 to 4,914.302
* BACnet/MSTP communication mode
N2 Device Address*
1
1 to 255
* N2 communication mode
BACnet Device Address*
4
4 to 127
* BACnet/MSTP communication mode
MSTP Baud Rate*
Auto
Auto, 1200, 9600, 19200, 38400, 76800
* BACnet/MSTP communication mode
BACnet Encoding Type
BACnet/MSTP Communication Mode
ISO 10646
(UCS-2)
ISO 10646 (UCS-2), ANSI X3.4
(US-ASCII)
Equipment Setup
General
Unit Type
4-Pipe
2-Pipe, 4-Pipe, VAV
Valve Open Voltage
10 VDC
0 to 10 VDC
Valve Closed Voltage
2 VDC
0 to 10 VDC
Supply Fan
Supply Fan Type*
Single Speed
Single Speed, Multi-speed, Variable
Speed
*Fan coil units only
Start Voltage*
2 VDC
0 to 10 VDC
*Fan coil units only, variable speed fan
Full Speed Voltage*
10 VDC
0 to 10 VDC, proportional
*Fan coil units only, variable speed fan
Min Command*
20%
0 to 100%
*Fan coil units only, variable speed fan
Med Fan Speed On Cmd*
33%
0 to 100%
*Fan coil units only, multi-speed fan
High Fan Speed On Cmd*
66%
0 to 100%
*Fan coil units only, multi-speed fan
Reheat
Reheat Installed
False
True or False. When set to True, the Aux
Output is used for Reheat Output.
