COOLIUS A10 - The Machine

11COOLIUS A10
3.2.2 The machine
1 LP pressure indicator
2 HP pressure indicator
3 Printer
5 Front cover
6 Rear wheel
7 Front wheel with brake
8 Ventilation Security System
inlet grid
9 Main switch
10 Transport safety of the
scale
11 Storage box for accesso-
ries
12 Container for UV leakage
additive 100ml
13 Container for new oil
250ml
14 Container for absorbed oil
250ml
15 LP quick coupling
16 HP quick coupling
17 LP hose
18 HP hose
1 2
5
7
6
3
g. 002 View Front
8
9
10
11
g. 003 View back
g. 004 View left
15
16
18
17
12
13
14
g. 005 View right
