Level 3 (Commission - Site data)
Download site data from PC
Note; PC software is only available to suitably trained Cooper Personnel, (it is not
available for purchase.)
Upload site data to PC / Download data from PC
Erase site data and reset.
NOTE: touching yes will permanently erase all site data, requiring a subsequent full re-
commissioning of the system.
This action will be stored in the log which cannot be erased.
When commissioning and configurating a new Easicheck installation, all neccessary data (e.g.
Luminaire location text, required test group allocation, battery type and quantity) can be inputted
via the touch screen display.
However to save time, when commissioned by Cooper Lighting and Safety personnel, a laptop
PC with special Cooper software can be used to considerably speed up the task.
The download data menu allows the data to be downloaded from the PC to the panel.
Specific instructions on uploading and downloading are provided with the upload / download
software.
This menu allows the configuration data to be uploaded from the panel to a computer where it
can be edited before being downloaded again back to the panel.
It also allows pre-programmed data to be downloaded from a computer to a panel.
This menu erases all existing site data and resets the panel, this would normally only be used
after major on site system reconfiguration.
To erase all site data, touch this button then touch either yes to confirm or back to abort.
Level 3 (Commission - Site data)
Back
Back
Back
Commission
Site data
Site data
Autolearn
Autolearn complete
Loop 1
Mute
Buzzzer
Mute
Buzzzer
Mute
Buzzze
Autolearn
Loop 1
Total addresses
SCAEL
Download data from PC
Loop 2
Erase site data and reset
Upload data to PC
Touching either button will instigate
auto learning of the selected loop,
once started autolearn cannot be
stopped until complete, this may
take a few minutes on a fully
loaded system
The panel will scan the loop
starting from the start of the loop
and allocate a sequential address
number to each found device. The
address number will begin with
address 1 for the first found device
on the loop, address 2 for the
second found device etc.
caution this will erase all
existing data, device text etc.
2
2
When autolearn is complete the result screen
will appear, this shows the total number of
devices found and also a breakdown of the
different types of devices found.
All devices now need to be configured with
location text, battery type, test group
allocation etc.
Back
Level 3
Commission
Mute
Buzzer
Site data
Network settings
Factory reset
Group allocation
System details
Printer Settings
Logo
