CUSTOMER MANUAL M400 DRIVE SYSTEM
Display content Explanation Display content Explanation
TEMP Current temperature Cycle Times Cycle Times
TotalVolt Battery voltage Max Uncharge Time Max Uncharge Time
Current current Last Uncharge Time Last Uncharge Time
Res Cap remaining battery capacity Total Cell The number of cell
Full Cap Battery capacity of Full charged Cell Voltage 1 Voltage Cell 1
RelChargeState Relative Charge in percentage Cell Voltage 2 Voltage Cell 2
AbsChargeState Absolute Charge in percentage Cell Voltage n Voltage Cell n
Briefly press
for two tiems (interval time is less than 0.5S) to exit back to main interface or select “BACK” → “BACK”
→ “EXIT” to exit back to the main interface.
⑶ “Error Code” history check
Briefly press (<0.5S)
or to select “Error Code” and briefly press (<0.5S) to enter into the interface. “E-CODE”
indicate the error information for last ten times. “E-CODE 1” represents the error content for the last time.
“E-CODE 10” represents the error content up to the tenth time. The maximum ten records can be kept. Error code “00”
means no error. Please see the error code table to know about the definition of the other codes.
