CUSTOMER MANUAL M400 DRIVE SYSTEM
92
6.3.4 Error Messages
DP C18.UART display can show e-bike faults. When a fault is
detected, the icon
will be indicated. One of the
following error codes will be indicated.
Error Explanation Troubleshooting
03 Brakes enabled Check whether a brake cable is stuck.
07 High voltage protection
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
08 Fault with motor hall sensor inside
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
10
The motor temperature reaches to the max
protection value
Stop the e-bike for a rest.
12 Fault with current sensor inside controller
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
13
Fault with temperature sensor inside
battery
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
21 Fault with wheel speed detecting sensor
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
22 BMS communication fault
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
25 Torque sensor torque signal fault
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
26 Torque sensor speed signal fault
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
30 Communication fault
Bring your Pedelec to your dealer or to a specialist to
have the error fixed.
Note: Error Code 10 will probably appear on the dispaly when the e-bike is climbling for a
long time. This indicates that the motor temperature has reached the protection value, in
which case the user needs to stop the e-bike for a rest. If the user continues to run the e-bike,
the motor will automatically cut off the power.
Error display
