12 SPECIFICATIONS
12.1 Battery
Primary Settings BT C01.340.UART BT C01.450.UART BT C01.600.UART BT C01.750.UART
Rated voltage 43 DCV 43 DCV 43 DCV 43 DCV
Nominal Capacity 7.8 Ah 10.4 Ah 14 Ah 17.5 Ah
Rate Capacity
6.43 Ah
(1C Discharge)
8.5 Ah
(1C Discharge)
11.4 Ah
(1C Discharge)
14.3 Ah
(1C Discharge)
Power 340 Wh 450 Wh 600 Wh 750 Wh
Charging time
4.5 h with a 2 A
Charger
6.5 h with a 2 A
Charger
5.5 h with a 3 A
Charger
6.5h with a 3 A
Charger
Operating temperature
during charging
0 – 45 °C 0 – 45 °C 0 – 45 °C 0 – 45 °C
Discharge -20 – 60 °C -20 – 60 °C -20 – 60 °C -20 – 60 °C
Storage (At 35% SOC
&-10° ~ 35 °C)
6 months 6 months 6 months 12 months
Maximum charging cycle
500 (60% SOC (@20
± 5 °C, Charge @
0.2°C and discharge
@ 0.5 °C))
500 (60% SOC (@20
± 5 °C, Charge @
0.2°C and discharge
@ 0.5 °C))
500 (60% SOC (@20
± 5 °C, Charge @
0.2°C and discharge
@ 0.5 °C))
500 (60% SOC (@20
± 5 °C, Charge @
0.2°C and discharge
@ 0.5 °C))
Riding Distance * Minimum 35 km Minimum 50 km Minimum 65 km Minimum 85 km
Dimensions (L * W * H) 408 x 123 x 70mm 408 x 123 x 70mm 408 x 123 x 70mm 408 x 123 x 70mm
Weight 3 kg 3.5 kg 3.5 kg 4 kg
Charger Special 5P charger Special 5P charger Special 5P charger Special 5P charger
* Ideal conditions: Flat terrain, approx. 15km/h average speed, no headwind, approx. 20 °C ambient temperature, high-quality bike components, tire tread and pres-
sure with minimal rolling resistance, experienced eBike rider(always shifts gears correctly), additional weight(excluding bike weight)<70kg.
12.2 Charger
