PWR_LED: Legacy Power LED header
PIN ASSIGNMENT 3
1
3 VCC
2 GND
1 VCC
SM_BUS: SMBUS header
PIN ASSIGNMENT 4
1
4 SM Data
3 GND
2 SM Clock
1 VCC
