22
INSTALL OVEN
1. Loo
p (do not tie) a 36" (91 cm) string around the conduit before the oven is
slid into place. This will keep the conduit from falling behind the oven.
2. Li
ft oven into cabinet cutout using the oven opening as a grip. Carefully
push against the oven front frame. Do not push against outside edges.
NOT
E:
• Ensure that no damage is done to oven gasket which lines the
edge of oven cavity.
3. Whi
le sliding the oven back, pull the string so that the conduit lies on the
top of the oven in a natural loop.
4. Whe
n you are sure the conduit is out of the way, carefully slide the oven
3/4" way back into the opening. Remove the string by pulling on one end
of the loop.
5. Usi
ng the mounting holes on the oven side trim as a guide, drill pilot holes
for mounting screws provided.
• Single oven: 2 screws, one on each side.
• Double oven: 4 screws, one on each side in both the upper and lower
ovens.
NOT
E:
• Mounting screws must be used. Failure to do so can result in the
oven falling out of the cabinet causing serious injury.
WARNING
EXCESSIVE WEIGHT HAZARD
• Use two or more people to move and install oven. Failure to do so can
result in back or other injury.
