23
NOTE:
6. Secure the oven to the cabinet with mounting screws provided.
• If the cabinet is particle board, you must use 3/4" particle board
screws. These may be purchased at any hardware store.
1. Verify that the hinge arms are extending forward.
2. Firmly grasp both sides of the door.
IMPORTANT: Do not lift door by door handle.
INSTALL OVEN DOOR
IMPORTANT: The oven door is heavy and fragile, and the door front is glass.
To avoid oven door glass breakage, use both hands, and grasp only the sides
of the oven door to remove. Do not lift oven door by door handle.
Assembling Door
3. With the door at the same angle as the removal position, which is
approximately five degrees or 2-3 inches from being fully closed, seat the
indentation of the hinge arms into the bottom edge of the hinge slots.
The notch in the hinge arms must be fully seated into the bottom edge of
the slots.
