INSTALLATION MANUAL GLOSSARY 11
The corner bracket is the piece that links the cover to the sleeves.
There is one in each corner of the Covana cover to ensure proper
weight distribution.
The corner brackets links the C-channels on the side to the ones in
front and back. It holds in place with 3 screws per C-channel. Never
use a power tool to screw hardware, as they might break.
The drive shaft transmits the power between the motor-side and
non-motor-side jack assemblies.
The escape hatch is a removable panel part of the cover. In case of
entrapment, the escape hatch is removable from the inside by
turning the locking mechanism.
The hammer block is a piece of plastic or wood used during the
installation to hit on the panels without damage. To use the hammer
block, insert the opening of the block on the foam panel. Ensure the
block is snugly fit on the panel before hammering.
The foot brackets are located in the part boxes. They provide a solid
footing for the Covana cover and are assembled with the jacks.
The front frame cut-out gets installed under the front step of your
hot tub. It links the two non-motor-side jacks.
