Description of main items of CPS SC20KTL-DO/US-480 &
SC14KTL-DO/US-208 (See Figure 2-3):
1. LCD key buttons: operate the functions and change settings of inverter
2. LCD display: indicates data
3. LED indicator lights: indicate the status of inverter
4. Holes for cable entry
5. DC switch: control the DC power on and off
6. AC switch: control the AC power on and off
7. Main housing
8. Wiring box
