Chapter 3 Installation
Below is the installation instruction of the inverter. Please read carefully
and install the product step-by-step.
1. CPS SC20KTL-DO/US-480 & SC14KTL-DO/US-208
Check and make sure that the following items are included in the package
before installation, as shown in Table 3-1.
Table 3-1 Main items
No.
Item
Q’ty
Note
(1)
CPS
SC20KTL-DO/US-480
or SC14KTL-DO
Grid-tied PV inverter
1
Grid-tied PV inverter
(2)
Mounting bracket
1
upon which Inverter
is hung and mounted
onto a wall
(3)
Installation and
operation manual
1
Installation and
operation manual
(4)
Accessory kit
1
contains all
necessary
accessories
The (5) Accessory kit contains items listed below:
Table 3-2 Accessories
Item
Q’ty
Purpose
M8x25 Expansion
bolts&nuts
8 pairs
for bracket installation
OT type terminal
1
for ground cable
