CPS SC Series - Basic Requirements for Installation

10
Pre-insulated end ferrule
20
16 for DC input cables, 4
for AC output cables
RJ45 connecters
4
for communication cables
Flange M5 nut
2
for grounding wire (1 nut for
backup use)
Red wire
1
for inverter with 1 MPPT
working alone
Black wire
1
for inverter with 1 MPPT
working alone
3.1 Basic requirements
 Check that the product environmental specifications (protection degree,
operating temperature range, humidity and altitude, etc) meet the
requirements of the specific project location;
 Make sure that the power grid voltage is within normal range;
 Ensure that the local electricity supply authority has granted permission
to connect to the grid;
 Ensure that local code requirement is met by enabling the AFCI function
from the LCD screen. This feature is disabled by default but can be
enabled in the field.
 Installation personnel must be qualified electricians or people who have
received professional training;
 Sufficient space is provided to allow the inverter cooling system to
operate normally;
 Install the inverter away from flammable and explosive substances;
 Avoid installing the inverter in locations that exceed the temperature
