CPS SC Series - Electrical Installation

19
bolts on each side, as shown in Figure 3-8.
Figure 3-8 Securing panels on both sides
3.3 Electrical installation
Inverter cable terminals of CPS SC20KTL-DO/US-480 & SC14KTL-DO
are shown in Figure 3-9:
INSTRUCTION:
Metal conduits shall be used as the cable protectors for wire
connection.
