Chapter 4 Operation
4.1 Start-up and shut-down
4.1.1 Start-up
Manual start-up: Manual start-up is required after initial installation or
manual (fault) shut-down. Move the cursor from the main operation interface
to “4 Setting”. Press ENTER and go to the password input area, enter
password“↑”“→”“↓”“←”, go to the submenu “1 ON/OFF”. Then move the cursor
to “ON” and press ENTER to start the inverter. Then the inverter will start up
and operate normally if the start-up condition is met. Otherwise, the inverter
stands by.
Automatic start-up: The inverter will start up automatically when the
output voltage and power of PV modules meet the set point, AC power grid is
normal, and the ambient temperature is within allowable operating range.
4.1.2 Shut-down
Manual shutdown : Normally, manual shutdown is not required. It can be
shut down manually if repair or maintenance is required. Move the cursor from
the main operation interface to “4 Setting”. Press ENTER and go to the
password input area, enter password“↑”“→”“↓”“←”, go to submenu “1 ON/OFF”..
Move the cursor to “OFF” and press ENTER, and then the inverter will be shut
down.
Automatic shutdown: The inverter will shut down automatically when the
output voltage and power of PV modules are lower than the set point, or AC
power grid fails; or the ambient temperature exceeds the normal range.
4.2 Operation mode
There are 4 operation modes. The following are corresponding indications
