5.3.7 Power Dispatch
(1) For CPS SC20KTL-DO/US-480 the following applies –
“ActivePower” and “PowerFactor” parameters can be set up through
LCD operations as well as remote control by software.
Local dispatch order: Service personnel can adjust the “ActivePower” and
“PowerFactor” parameters through LCD operations. For detailed setup steps,
please refer to “5.3.8 System protection parameters setup”.
The current parameters of “ActivePower” and “PowerFactor” can be
checked by the following steps.
Move the cursor to “5 Dispatch” in the main interface, as shown in Figure
5-12:
1 OP. Info
2 Alarm
3 History
→4 Setting
5 Dispatch
Figure 5-12 Contents indicated on the main operation interface
Press ENTER to the interface shown in Figure 5-13.
ActivePower(%)
100.0
PowerFactor
1.000
Figure 5-13 Parameters of power dispatch
Remote dispatch method: The “ActivePower” and “PowerFactor”
