CPS SC Series - System, Environment, and Safety Data

70
Grid Connection Type
3Φ / N / PE
3Φ / N / PE (Optional
Neutral Connection)
Max AC Output Current
39A
24A
Rated Output Frequency
60Hz
Output Frequency Range
59.3-60.5Hz
Power Factor
>0.99 (Adjustable +/- 0.9)
Current THD
<3%
AC Disconnection Type
Switch
System
Topology
Transformerless
Max. Efficiency
96.7%
97.4%
CEC Efficiency
96.0%
97.0%
Stand-by / Night
Consumption
<20W / <2W
Environment
Protection Degree
NEMA 4 (IP65)
Cooling
Variable speed cooling fans
Operating Temperature
Range
-13°F to +140°F / - 25°C to +60°C (derating
from +50°C / +122°F)
Storage Temperature Range
-22°F to +158°F/- 30°C to +70°C
Operating Humidity
0-95%, non-condensing
Operating Altitude
6562ft / 2000m (derating from 4921ft / 1500m)
Display and Communication
Display
LCD + LED
Communication
RS485 (Modbus)
Mechanical Data
Dimensions (WxHxD)
21.4x41.6x8.5in / 544x1058x215mm
Weight
141lbs / 64kg
