Assembling Your Router Table
Before beginning this process, consult
the Router Table Inventory section to
ensure all components are available
and the Required Setup Tools section
to aid in the assembly of the table. Be
sure to clean any parts that are
coated in rust preventative.
Assembly Steps:
1. Locate the four table legs and two
lower braces. Using the 5/16 -18 x
½” flange bolts, attach the lower
braces to the legs as shown in
(Fig.12).
2. Install the (4) adjustable feet to
the bottom of the table legs, as
per (Fig.12).
Figure 12
3. Connect the leg assemblies with
the (4) long braces supplied with
the 5/16-18 x ½” flange bolts as
shown in (Fig.13 & Fig.14)
Figure 13
Figure 14
4. Place the tabletop upside down on
a flat surface and using 5/16-18 x
½” flange bolts attach the upper
short braces to the table as in
(Fig.15).
