5. Pull Rod Installation 拉杆安装
10
M5×12 Hexagon flat round
head screw x2
M5x12 内六角平圆头螺丝
11
M5x20 Hexagon flat round
head screws x2
M5x20 内六角平圆头螺丝
Adjust the proper length of assembled pull rod and install in the position shown in the figure
拉杆组装调节到合适的长度，安装在图示位置
10
11
11
10
M5 Large Flat gasket
M5加大平垫
×2
12
12
05
