Creality LD-002R User Manual

Release Film Instructions
Installation steps:
a) First, remove the 14 screws at the bottom of the tray and take out broken release film.
b) Then place the release film between the two steel frames.
c) Finally, put the assembled steel frame back into the tray and tighten 14 screws.
d) The installed release film is as shown.
Parameters
Size
140mm*200mm
Thickness
0.15-0.2mm
Light Transmittance
95%

Creality LD-002R Specifications

General

Technology	LCD-based SLA
Build Volume	119 x 65 x 160 mm
Z-axis Positioning Accuracy	0.00125 mm
Print Speed	20-30 mm/h
Connectivity	USB
Software	ChiTuBox
Power Supply	100-240V, 50/60Hz
Operating System	Windows, Mac OS
Resin Compatibility	405 nm UV resin
XY Resolution	0.047mm (2560 x 1440)
Light Source	UV LED
Supported File Formats	STL
Printer Dimensions	221 x 221 x 403 mm
