Crestron TS-70 Series User Manual

40 • TS-70 Series Product Manual — Doc. 8555F
LANPoE (1) 8-pin RJ-45 connector, female, with 2 LEDindicators;
100BASE-TX Ethernet port;
PoE+ PD port;
Green and yellow LEDs indicate Ethernet port status
USB (1)USB Type-Aconnector, female;
USB 2.0 host port
Power
PoE(Power over
Ethernet)
IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
Requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power
management;
Requests 30 W (PoE+Class 4) from an 802.3at Type 2 PSE without LLDP;
Requests 15.4 W (PoEClass 0) from an 802.3af (or 802.3at Type 1)PSE
Environmental
Temperature 32 to 104°F (0 to 40°C)
Humidity 10% to 95% RH (noncondensing)
Heat Dissipation 44BTU/hr
Construction
Housing Plastic, smooth black or white finish, edge-to-edge glass with black or white
surround
Dimensions
Height 4.02in. (102mm)
Width 6.87in. (175mm)
Depth 4.37in. (111mm)
