Product Manual — Doc. 8555F TS-70 Series • 5
NOTE: The Zoom ultrasonic proximity signal is supported up to an average of 9ft (2.74m)
from the TS-770 touch screen to an end user device. The range will vary based on
environmental noise, the sensitivity of the end user device, and the orientation to the touch
screen.
Crestron Home OSControl
The TS-770 may be used to control a Crestron Home™ OS whole home solution. Select the
Crestron Home app from the touch screen to control lighting, shades, climate, media, security,
and cameras, including the ability to create and recall scenes that create a desired ambiance
throughout a home. A TS-770 may be installed in each room to provide easy access to various
Crestron Home functions for both the room and the home.
Bluetooth Beacon
The built-in Bluetooth® proximity detection beacon enhances the intelligence and personalization
of a Crestron system by enabling a smartphone or tablet device to always know what room it is
in. It works with the Crestron Go App and Crestron App to determine when the mobile device is
in or near the same room as the beacon, and signals the mobile app to automatically display the
appropriate controls and information for the room.
2,8
Web Browsing
Using its built-in web browser, the TS-770 provides access to online program guides and other
web-based services, and it can be used to control DVRs and other devices without having to pick
up a separate tablet or smartphone.
1
Wired and Wi-Fi Connectivity
An Ethernet LAN connection is all that is required to wire the TS-770, containing all control,
video, intercom, and power signals within a single wire.
For deployments without access to Ethernet, the touch screen can also be connected the
network over Wi-Fi communications via a local wireless access point (WAP).
Power over Ethernet
Using PoE technology, the TS-770 gets its operating power directly through the network cable.
PoE (Power over Ethernet) eliminates the need for a local power supply or any dedicated power
wiring. Crestron PoE switches (CEN-SW-POE-5 or CEN-SWPOE-16
3
) offer a total networking
solution with built-in PoE for multiple touch screens. A PoE Injector (PWE-4803RU
3
) is also
available to support a single touch screen.
NOTE: Refer to the “Power” specifications for more details.
High-Speed USBPort
The TS-770 provides a high-speed USB2.0 port for connecting supported Crestron accessories
to the touch screen.
3
