Crestron TSR-310 User Manual

User Guide – DOC. 8421A TSR-310: Handheld Touch Screen Remote • 21
Shades
If shade motors have been added to the Crestron Pyng system, swipe through the main
carousel screens until the
SHADES screen is displayed.
NOTE: If all media and environmental subsystems are active in the Crestron Pyng
system, the SHADES screen is the second screen from the right as indicated by the
navigation dots on the bottom of the screen.
SHADES Screen
Use the SHADES screen to recall shade scenes for the room where the TSR-310 is paired
or for the whole house. The
SHADES screen also provides master raise and lower
controls for programmed shade motors or groups in the room.
Shade scenes are used to set predefined levels for multiple shade motors when recalled.
To adjust the master shade position in the room:
• Tap the small sun icon at the bottom left of the screen to lower the shade
position incrementally.
• Tap the large sun icon at the bottom right of the screen to raise the shade
position incrementally.
The MY SCENES menu contains all of the shade scenes that may be recalled from the
room. The room where the shade scene will be recalled is displayed under the scene
name. All of the scenes for the room where the remote is paired are listed first, followed
by any scenes for other rooms.
