operation, always leave valve in automatic position. Test the valve monthly to
confirm valve opens and closes. Unplug valve from unit to confirm water stops
flowing.
Caution: Do not allow solder or solder flux to fall in or on the unit.
Step 5: Connect the remaining piping to the top Stainless flexible hose at the top
of the unit – do not use PVC pipe or braided hose. Make sure the sealing
washer is inside the end of the hose before making the connection. Do not bend
the flexible hose excessively. Tighten securely. Add pipe insulation to all
overhead piping to prevent condensation from dripping onto unit.
Step 6: Caution: do not allow the inside of the unit to get wet. Before
opening the water supply, double check all connections and cover the top of the
unit with a rag or some plastic to prevent water entry. Close any faucets you
opened in Step 1 and then slowly turn on the water supply to check for leaks. If
leaks exist, investigate the cause and repair. Caution: Do not connect the unit to
electrical power until the piping and unit are free of water leaks. The solenoid
valve can be placed into manual mode to allow water to enter the unit. Switch
back to automatic mode when done.
Step 7: Once the system is checked for leaks, install pipe insulation on the outlet
hose and piping to prevent condensation from falling onto or into the unit.
PARALLEL INSTALLATION
When more than one unit is installed in parallel (flow split between units), the
units must be installed with manual shutoff valves both upstream and
downstream of each unit. This allows one unit to be serviced without interrupting
the flow to the other units. Another requirement is the installation of a check valve
downstream of the unit (after the unit). This will prevent the backflow of water to a
unit. See Figure 1E.
