Cold Air Kit
If cold room conditions cannot be avoided, the Cold Air Kit should be installed.
The kit consists of two cover plates and two lamp insulators. The cover plates are
to be placed on the top aluminum plate to cover the convection holes. The lamp
insulators are to be wrapped around the bottom of the lamps just below the
bottom aluminum plate. See Figure 1G.
If during the summer months the room temperature exceeds 20°C (68°F), the
Cold Air Kit may be removed and then reinstalled for winter months only.
COVER PLATE
TOP VIEW OF UNIT
LAMP
INSULATOR
BOTTOM VIEW OF UNIT
Figure 1G
