Parts Included

• Hallett UV system complete with integral wall brackets (1)

• Instruction manual (1)

• Product & warranty registration card (1)

• Power cord (1) (located within packaging)

• Stainless flexible hoses (2) per system – Hallett 13: one ¾” straight hose

for bottom (inlet), one ¾” bent hose for top (outlet)

Hallett 30: one 1” hose for bottom (inlet), one 1” hose for top (outlet)

(hoses located within packaging)

• Solenoid valve (1) 3/4" for Hallett 13; 1” for Hallett 30

• Ultraviolet lamps (2) – installed within the unit

• External dry contact for remote monitoring or optional autodialer.

Optional - Pre-treatment sediment and or carbon filter to remove water

particles, odor or trace chemicals for improved taste.

• Pipe wrap insulation for top hose

• Cold Air Kit complete with installation instructions

Other Materials Needed

The Hallett requires male NPT fittings for the hose connections and also the

solenoid valve (make a note of the size ¾”, 1”). These fittings and any piping

compatible with the plumbing should be on hand before you begin installation.

See Figure 1B and make a list of all necessary components including solder,

paste and thread sealant. Bypass piping and valves that isolate the unit are

optional, as is a drain valve for draining the unit.

Pipe insulation is provided to wrap around the top hose coming out from

the unit. Any other piping overhead must also be wrapped to prevent

condensation from dripping back onto the unit.

Note: Teflon tape and thread sealant are not required to connect the Stainless

flexible hoses to the Hallett or to the plumbing system – the FIP connectors mate

with male NPT (National Pipe-Taper) fittings. The rubber washer in each end of

the hose provides the seal. Ensure that the washer is in place before making the

connection.

Tools Needed

• pipe cutter, torch and other typical plumbing tools for modifying piping

• Wrench for tightening hose connections

• Phillips screwdriver

• Slotted screwdriver

Do not operate a unit that has been damaged or that is missing any components.

If a part is missing from your Hallett, contact your dealer.
