Page 13
VIEW MEMORY MODE
This Elite alarm panel has an event memory which stores the most recent events, (up to 255), including all alarm
events, all system events such as mains failure etc as well as arming by Area. This event memory is displayed via
the standard keypad with the most recent event shown first and subsequent events following in descending order
from newest to oldest.
The "MEMORY" light will flash on and off when there is a new event in memory which has not been viewed. To
stop the "MEMORY" light flashing, simply press the MEMORY button and the event memory will be flashed back to
you with the most recent event shown first. To cancel the memory display just press “ENTER”. Each event is
separated by a beep tone. The memory light will also stop flashing when the system is armed.
Current System Alarms
When viewing the memory event buffer at the keypad by pressing the “MEMORY” button, the first thing that will
always be displayed is the Current System Alarms that are still present. The Current System Alarms are indicated
by the Memory/Mains & Battery LEDS being on plus a zone LED from 1-8 to indicate the system alarm/s present. If
no Zone LED’s are on at this time, it means that there are no current system alarms. If a zone LED or LED’s are On
then this indicates system alarms that have not yet cleared. The zone LED’s 1-8 are pre-defined as to what system
alarm they will display. These system alarm indications are shown in the table below. Following the display of
current system alarms the panel will then sequence through the 255 historical memory events starting at the most
recent event. The second table shows the alarm events that can be displayed in memory mode and what indicators
are used to show them.
HISTORICAL EVENT DISPLAY CHART
EVENT DEVICE INDICATOR STATUS
ACTIVATION
Zones 1-16 LED's 1-16 On Steady
BYPASS Zones 1-16 BYPASS
LED's 1-16
On Steady
On Steady
DETECTOR TAMPER
(SHORT CIRCUIT)
Zones 1-8 TAMPER
LED's 1-8
Flashing
On Steady
DETECTOR TAMPER
(OPEN CIRCUIT)
Zones 9-16 TAMPER
LED's 9-16
Flashing
On Steady
CABINET TAMPER
Cabinet or Satellite Siren TAMPER Flashing
WRONG CODE ALARM
Code Tamper at
Keypad #
TAMPER
LED’s 1-8
On Steady
On Steady
CROW KEYPAD TAMPER SWITCH
ACTIVATED
Keypad Tamper Alarm at
Keypad #
TAMPER
LED’s 1-8
On Steady
On Steady
LOW BATTERY Controller Battery BATTERY Flashing
MAINS FAILURE Controller Mains Supply MAINS Flashing
FUSE FAILURE (F1 or F2)
Controller on-board fuses MAINS Flashing
LED # 1
Battery Low
LED # 5
Radio Pendant Battery Low
LED # 2 Mains or 12V Fuse Failure LED # 6 Supervised Detector Failure
LED # 3 Telephone Line Failure LED # 7 Zone Inactivity Timeout
LED # 4
Radio Detector Battery Low
LED # 8
Dialler Kiss-off Failure
CURRENT SYSTEM ALARMS
