Crow PowerWave-4 - Hour Alarms to Outputs; Day Zones to Outputs; Zone Tamper Alarms to Outputs

Page 17
MAPPING 24 HOUR ZONE ALARMS TO OUTPUT
24 HOUR ZONE ALARM MAPPING TO OUTPUTS - P71E - P78E
When a 24 Hour zone is in alarm this block of addresses allows individual zones to be mapped to
selected outputs. The default setting is that zones 1-4 will turn on output 2 only when a 24 Hour
alarm occurs.
P71E 24 Hour Zone Alarms to Output #1. Options=Zones 1-4 (Default=1-4)
P72E 24 Hour Zone Alarms to Output #2. Options=Zones 1-4 (Default=1-4)
P73E 24 Hour Zone Alarms to Output #3. Options=Zones 1-4 (Default=None)
P74E 24 Hour Zone Alarms to Output #4. Options=Zones 1-4 (Default=None)
P75E 24 Hour Zone Alarms to Output #5. Options=Zones 1-4 (Default=None)
P76E 24 Hour Zone Alarms to Output #6. Options=Zones 1-4 (Default=None)
P77E 24 Hour Zone Alarms to Output #7. Options=Zones 1-4 (Default=None)
P78E 24 Hour Zone Alarms to Output #8. Options=Zones 1-4 (Default=None)
MAPPING DAY ZONES TO OUTPUTS
DAY ZONES TO OUTPUTS - P81E - P88E
When a Day zone is unsealed this block of addresses allows individual zones to be mapped to
selected outputs. The default setting is that no Day zones are mapped to any of the 8 outputs.
P81E Day Zones to Output #1. Options=Zones 1-4 (Default=None)
P82E Day Zones to Output #2. Options=Zones 1-4 (Default=None)
P83E Day Zones to Output #3. Options=Zones 1-4 (Default=None)
P84E Day Zones to Output #4. Options=Zones 1-4 (Default=None)
P85E Day Zones to Output #5. Options=Zones 1-4 (Default=None)
P86E Day Zones to Output #6. Options=Zones 1-4 (Default=None)
P87E Day Zones to Output #7. Options=Zones 1-4 (Default=None)
P88E Day Zones to Output #8. Options=Zones 1-4 (Default=None)
MAPPING ZONE TAMPERS TO OUTPUTS
ZONE TAMPER MAPPING TO OUTPUTS - P91E - P98E
When a zone input is set for Dual-End-of-Line (P130E) the short & open circuit tampers are
automatically enabled for that zone input. This option allows the zone tamper alarms to be mapped
through to individual outputs. Led 1-4 is a short on the Zone 1-4 and a Led 5-8 is an open loop in
Zone 1-4.
P91E Zone Tamper to Output #1. Options= Zone Tampers 1-8 (Default=1-8)
P92E Zone Tamper to Output #2. Options= Zone Tampers 1-8 (Default=1-8)
P93E Zone Tamper to Output #3. Options= Zone Tampers 1-8 (Default=1-8)
P94E Zone Tamper to Output #4. Options= Zone Tampers 1-8 (Default=None)
P95E Zone Tamper to Output #5. Options= Zone Tampers 1-8 (Default=None)
P96E Zone Tamper to Output #6. Options= Zone Tampers 1-8 (Default=None)
P97E Zone Tamper to Output #7. Options= Zone Tampers 1-8 (Default=None)
P98E Zone Tamper to Output #8. Options= Zone Tampers 1-8 (Default=None)
1 2 3 4 5 6 7 8
24 Alarm O/P 1
Chime To O/P 1
- - - - - - - -
1 2 3 4 5 6 7 8
Tamper To O/P 1
