will change the arm/disarm state). The panel tamper input is used to provide the key-switch function.
PARTITION “B” OUTPUT OPTIONS
PARTITION “B” OUTPUT OPTIONS - P121E - P128E
This block of addresses sets a number of output options which are specific and unique to the operation of partition
or Area "B". Activity in Areas "A" will have no direct effect on the options set at these addresses.
P121E 1E Arm status to output- Default off
2E Stay Mode on status to output- Default off
3E Disarm status to output- Default off
4E Pendant chirps for Arm to output - Default off
5E Pendant chirps for Stay Mode On to output - Default off
6E Pendant chirps for Disarm to output - Default off
7E Pulse on Arming to output - Default off (P124E=ON)
8E Pulse on Disarming to output - Default off
Option 1 Arm indication to output - This option will turn the output on when Area "B" is armed. The output
will turn on at the start of the exit delay and turn off when the Area is disarmed. The output reset time
should be set to zero.
Option 2 Stay Mode On indication to output - This option will turn the output on when Area "B" Stay Mode is
armed. The output will turn on at the start of the exit delay and turn off when Stay Mode is disarmed.
The output reset time should be set to zero.
Option 3 Disarm indication to output - This option will turn the output on when Area "B" is Disarmed. The
output will turn on when the Area “B” is disarmed and turn off when the Area is Armed or in Stay
Mode. The output reset time should be set to zero.
Option 4 Pendant Chirps for Arm to output - This option will map two short pulses (Chirps) to the output
when Area "B" is armed via a radio key (Pendant) ,( the length of the pulses is set by the pulse timer
P221E-P228E).
Option 5 Pendant Chirps for Stay Mode On to output - This option will map two short pulses (Chirps) to the
output when Area "B" Stay Mode is set via a radio key (Pendant) ,( the length of the pulses is set by
the pulse timer P221E-P228E).
Option 6 Pendant Chirps for Disarm to output - This option will map four short pulses (Chirps) to the output
when Area "B" is Disarmed via a radio key (Pendant) ,( the length of the pulses is set by the pulse
timer P221E-P228E).
Option 7 Pulse on Arming to output - This option will map a pulse to the Output each time Area "B" is armed
( the length of the pulses is set by the pulse timer P221E-P228E).
Option 8 Pulse on Disarming to output - This option will map a pulse to the Output each time Area "B" is
disarmed ( the length of the pulses is set by the pulse timer P221E-P228E).
Note: P122E through P128E are as above but applied to outputs 2-8
- - - 4 5 - - -
AreaB Option
AreaB Opt O/P 1
- - - - - - - -
