All Walk test activities will go into the event memory for display via the LCD keypad or LED keypad ,
In memory display mode
P627E Walk-test Mode
WRITE TO EEPROM (DTU) BOARD
This address (P628E) is used to copy the panels program configuration to an external EPROM memory card (DTU-
Data Transfer Unit) which can be plugged into the expansion socket on the control board.
P628E Write to EEPROM (DTU) Board
READ FROM EEPROM (DTU) BOARD
This address (P629E) is used to return the panels program configuration from an external EPROM memory card
(DTU-Data Transfer Unit) which can be plugged into the expansion socket on the control board.
P629E Read from EEPROM (DTU) Board
Walk Test Mode
- - - - - - - -
Read fromEEPROM
Write To EEPROM
Done
Done
To Next Page
