Page 27
Option 11 Ness Battery Low - If a Ness radio pendant or PIR is used on the PW-4 radio zone input, setting this
bit allows the panel to correctly recognize the battery low signal from Ness devices.
Option 12 Ness Radio Reed Switch - If a Ness radio reed switch is used on the PW-4 radio zone input, setting
this bit allows the panel to correctly recognize the battery low signal from Ness device. This bit also
recognizes the open and closed signals from the reed switch so the zone Led can follow the correct
state of the reed switch (ie open or closed)
Option 21 Electronics Line Radio PIR- If an Electronics Line radio PIR is used on the PW-4 radio zone input,
setting this bit allows the panel to correctly recognize the alarm, tamper & battery low signal from EL
device.
Option 31 Visonic Radio PIR- If a Visonic K900 radio PIR is used on the PW-4 radio zone input, setting this bit
allows the panel to correctly recognize the alarm, tamper & battery low signal from the device.
Option 32 Visonic Powercode (unsupervised) - If a Visonic Powercode radio device is used on the PW-4
radio zone input, setting this bit allows the panel to correctly recognize the alarm and battery low
signal from the device but the supervised signal is ignored.
Option 33 Visonic Powercode (supervised) - If the Visonic Powercode range of radio PIR or reed switch are
used on the PW-4 radio zone input, setting this bit allows the panel to correctly recognize the alarm,
tamper & battery low signal from the device. Setting this option on also starts a 4 hour timer for the
supervised signal. The 4 hour timer is constantly being reset while valid supervised signals are being
received every 1-1.5 hours. If no supervised signals are received from the PIR within the 4 hour
period, a supervised alarm is generated.
Note: P232E through P234E are as above but applied to zones 2-4
RADIO ZONE SUPERVISED TIMER
P239E RADIO ZONE SUPERVISED TIMER - Default= 240 Minutes (Value 0-255 Minutes)
RADIO PENDANT CODE LOAD
To load a radio pendant on the panel, press the appropriate address number (e.g. P614E for
Pendant 4). The keypad buzzer will beep once a second to indicate learn mode has been initiated
and the Led on the RX-40 board will flash. The radio pendant you wish to load must transmit a signal
within 30 seconds of entering learn mode otherwise the panel will time out and no code will be
loaded. If a valid code is received within the 30 seconds the keypad will give 3 short beeps and exit
learn mode. To remove a loaded radio pendant at a single address only, enter in the code load
address as above eg P614E, then without operating the transmitter and before the 30 second timer
expires press the “Enter” button. This will remove the code loaded against this address (in this case
radio pendant 4).
P611E Load Radio Pendant # 1
P612E Load Radio Pendant # 2
P613E Load Radio Pendant # 3
P614E Load Radio Pendant # 4
P615E Load Radio Pendant # 5
Radio Zone 1 Type
4
SuperVised Timer
240
Learn Pendant 1
Learning
