Page 28
P616E Load Radio Pendant # 6
P617E Load Radio Pendant # 7
P618E Load Radio Pendant # 8
RADIO PENDANT OPTIONS “A”
RADIO PENDANT OPTIONS “A”- P151E-P158E
This block of addresses (P151E - P158E) are used to select the operational settings for each of the 8 radio
pendants. Functions such as arm only, disarm only or both can be selected for each pendant independently.
P151E-Pendant #1 Options 1E Assigned to Partition “A” - Default on
2E Assigned to Partition “B” - Default off
3E Pendant can Arm the system - Default on
4E Pendant can Disarm the system - Default on
5E Pendant can turn Stay Mode On - Default off
6E Pendant can turn Stay Mode Off - Default off
7E Spare - Default off
8E Pendant is disabled if panel is in alarm - Default off
Option 1 Assigned to Partition “A” - This option assigns the pendant to partition “A”. The pendant must be
assigned to at least one partition to allow it to perform arm/disarm functions. The pendant can be
assigned to both partitions if required.
Option 2 Assigned to Partition “B” - This option assigns the pendant to partition “B”. The pendant must be
assigned to at least one partition to allow it to perform arm/disarm functions. The pendant can be
assigned to both partitions if required.
Option 3 Pendant can Arm - This option assigns the Arm function to a pendant. The partition/s it will arm has to
be selected at options 1 & 2.
Option 4 Pendant can Disarm - This option assigns the Disarm function to a pendant. The partition/s it will
disarm has to be selected at options 1 & 2.
Option 5 Pendant can turn Stay Mode On - This option assigns the Stay Mode Arm function to a pendant. The
partition/s it will arm has to be selected at options 1 & 2. If Stay Mode arming is to be used for this
pendant then Options 2 & 3 should be turned off.
Option 6 Pendant can turn Stay Mode Off - This option assigns the Stay Mode Disarm function to a pendant.
The partition/s it will disarm has to be selected at options 1 & 2. If Stay Mode disarming is to be used for
this pendant then Options 2 & 3 should be turned off.
Option 7 Spare
Option 8 Pendant Disabled if panel is in Alarm - This option stops the pendant from working while the panel is
in alarm. This feature should only be set if you feel that a pendant with disarming functions could be
prone to misuse in an alarm condition.
Note: P152E through P158E are as above but applied to pendants 2-8
RADIO PENDANT OPTIONS “B”
RADIO PENDANT OPTIONS “B”- P161E-P168E
This block of addresses (P161E - P168E) are used to select output control and Panic options for each of the 8 radio
Pendant 1 Opt A
1 - 3 4 - - - -
Pendant 1 Opt A
