PROGRAMMING TELEPHONE NUMBERS
The panel can be programmed with up 4 telephone numbers. The numbers can be up 16 digits long. Dial modifiers
such as Pause can be programmed into the number sequence as per the chart below. See the table on page 32 for
more information on the special telephone number characters/modifiers.
LED KEYPAD LCD KEYPAD FUNCTION TO BE PROGRAMMED LED KEYPAD INDICATION
BUTTON BUTTON
“Panic” Control 2 # READY/BYP
“Memory” Control 3 * SYSTEM
“Control” Control 4 2.5 sec Pause TROUBLE
“Arm” Control 5 Wait for 2nd Dial tone READY/BYP & SYSTEM
“Stay” Control 6 5 sec Pause READY/EXCL & TROUBLE
P501E Telephone # 1 - Value = 1-16 digits
P502E Telephone # 2 - Value = 1-16 digits
P503E Telephone # 3 - Value = 1-16 digits
P504E Telephone # 4 - Value = 1-16 digits
MAXIMUM RE-TRIES PER TELEPHONE NUMBER
The addresses (P245E-P248E) are used to select the maximum number of dial attempts the panel will make for each
telephone number
P245E Maximum Dial Attempts for Ph # 1 - Value 0-99 (Default = 20)
P246E Maximum Dial Attempts for Ph # 2 - Value 0-99 (Default = 20)
P247E Maximum Dial Attempts for Ph # 3 - Value 0-99 (Default = 20)
P248E Maximum Dial Attempts for Ph # 4 - Value 0-99 (Default = 20)
PROGRAMMING TELEPHONE NUMBER REPORT FORMAT
This block of addresses (P241E - P244E) are used to set the reporting format which will be sent when an alarm
occurs for each of the telephone numbers.
P241E-Telephone #1 Options 1E Contact ID
(Default = 2) 2E Domestic Dial
3E Pager
4E Voice Dialer
5E 4 + 2 (Pulsed) 10 pps (1400 hz Handshake, 1800 hz transmit Tone)
6E 4 + 2 (Pulsed) 10 pps (1400 hz Handshake, 1900 hz transmit Tone)
7E 4 + 2 (Pulsed) 10 pps (2300 hz Handshake, 1800 hz transmit Tone)
8E 4 + 2 (Pulsed) 10 pps (2300 hz Handshake, 1900 hz transmit Tone)
9E 4 + 2 (Pulsed) 20 pps (1400 hz Handshake, 1800 hz transmit Tone)
10E 4 + 2 (Pulsed) 20 pps (1400 hz Handshake, 1900 hz transmit Tone)
11E 4 + 2 (Pulsed) 20 pps (2300 hz Handshake, 1800 hz transmit Tone)
12E 4 + 2 (Pulsed) 20 pps (2300 hz Handshake, 1900 hz transmit Tone)
13E 4 + 2 DTMF
