2.14 T4 Aspirator Plate
The aspirator plate can be used in scenarios where sampling from an area may be required.
The hand aspirator bulb (part number AC0504) will also be required.
Fit the aspirator plate
À into the groove on the left hand side of the T4 rst Á, ensuring the at part
of the cap faces the bottom of the T4 and the text is the correct way up, then click the right hand side
in place Â.
Figure 9: Attaching the Aspirator Plate
The hose end
à of the hand aspirator bulb must then be attached to the aspirator plate port Ä on
the right hand side (as viewed from the front) adjacent to the arrow head on the aspirator plate.
Figure 10: Attaching the Hand Aspirator
À
Á
Â
Ã
Ä
