MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-7
©2000 Crown International, Inc.
7.3 Middle Chassis Assembly
NotesItem # QTY Part Number Description
1 1 F12701-3 Chassis
2 1 --- Divider Assembly See Section 7.5
3 2 D 7927-3 Capacitor Holder, Inner
4 2 D 7928-1 Capacitor Holder, Outer
5 1 M46664-5 Ch 2 Bi-Level Switch Assby See Section 7.8
6 2 D 7870-5 Valox Washer
7 6 A10100-10 Flat Washer, #8
8 6 A10094-6 Lock Washer, #8 Int Star
9 2 A10089-70820 Screw, 8-32 X 1.25
10 1 M46665-2 Ch 1 Bi-Level Switch Assby See Section 7.7
11 2 A10089-10808 Screw, 8-32 X .5
12 4 D 7871-3 Valox Spacer
13 2 D 7818-4 Output Slide Guide
14 1 --- PIP Terminator Assembly See Section 7.9
15 1 --- Ch 1 Output Assembly See Section 7.12 (Ch 1 & 2 are identical)
16 2 A10089-10612 Screw, 6-32 X .75
17 2 A10094-4 Lock Washer, #6 Int Star
18 2 A10100-4 Flat Washer, #6
19 1 --- Ch 2 Output Assembly See Section 7.12 (Ch 1 & 2 are identical)
20 13 C 8874-7 Screw, 8-18 X .375 sht mtl
21 15 A10094-5 Lock Washer, #8 Int Str Blk
22 15 F12567J7 Bottom Cover
23 4 A10109-70604 Screw , 6-32 X .25 Black
24 2 A10089-70844 Screw, 8-32 X 2.75
25 2 A10100-12 Washer, 3/16 X 9/16 X 1/16
