MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-9
©2000 Crown International, Inc.
7.4 Rear Chassis Assembly
1 1 F12176J7 Top Cover
2 - --- Main Board Tray Assembly See Section 7.11
3 1 128302-1 Back Panel
4 1 F12302J9 Box Shield Output post protective cover
5 1 102745-1 PIP2-FXQ
6 4 C 8874-7 Screw, 8-18 X .375 Sht Mtl
7 13 A10089-70806 Screw, 8-32 X .375
8 17 A10094-5 Lock Washer, #8 Int Str Blk
NotesItem # QTY Part Number Description
