MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-17
©2000 Crown International, Inc.
7.8 Ch 2 Bi-Level Switch Assembly (M46664-5)
NotesDescriptionItem # QTY Part Number
1 2 D 7882-0 15000µF Capacitor C800, C802
2 1 P10357-5 Insulator: Ch 1 & 2 #1
3 1 M21074-6 Plate: Ch 2 -Vcc #1
4 1 D 7824-2 Insulator: Ch 2 #2
5 3 C 6541-4 Torque Spreader
6 3 C 9927-2 MOSFETs Q800, Q801, Q802
7 3 A11397-003 Lead Insulation Tube
8 3 C 8341-7 Ferrite Bead FB4, FB5, FB6
9 1 M21075-3 Plate: Ch 2 FET #2
10 - --- Wires
11 1 D 7825-9 Insulator: Ch 1 & 2 #3
12 1 M21076-1 Plate: Ch 2 Diode #3
13 1 D 7820-0 Insulator: Ch 2 #4
14 1 M21077-9 Plate: Ch 2 +Vcc #4
15 1 A10086-11008 Screw, 10-32 X .5
16 1 D 2934-4 Solder Lug
17 11 A10094-4 Lock Washer, #6
18 9 A10086-10604 Screw, 6-32 X .25
19 1 A10086-11006 Screw, 10-32 X .375
20 1 A10086-11005 Screw, 10-32 X .312
21 2 C 8855-6 Dual Diode D800, D801
22 2 A10102-5 Hex Nut, 6-32
23 1 H43479-7 Header (with wires)
24 1 D 7843-2 Switch Board Ch 2 (Ch 2 half of blank part D 7843-2)
25 1 D 7880-4 Insulator: Ch 1 & 2 #5
26 1 A10086-11009 Screw, 10-32 X .562
27 4 A10094-8 Lock Washer, #10
28 8 A10101-26 Nylon Washer
To Next Page
